Description
Setting: 1.5 bar ±10%
materials
- Body: Brass
- Base: Black nylon
- Contacts: Silver
- Seal: HNBR
Specifications
- Maximum operating pressure: 40 bar
- Proof pressure: 60 bar
- Operating temperature: -25 °C to +80 °C
- Compatibility with liquids: Mineral oils, synthetic fluids, HFA, HFB, HFC according to ISO 2943
- Protection class: IP65 according to EN 60529
Electrical data
- Electrical connection: EN 175301-803
- Resistant load:
- 5 A / 14 VDC
- 4 A / 30 VDC
- 5 A / 125 VAC
- 4 A / 250 VAC
