Description
These valves are adjustable, non-compensated flow limiters. The built-in check valve around the control port allows free flow in one direction and metered flow in the other.
Control is available only in port A, port B only, or both ports (A and B) for type "X" (inflow throttle) or type "Y" (outflow throttle). Port P is only available in type "X" (inflow throttle) and does not include a return valve.
The flow setting can be adjusted using an Allen wrench and locking nut, a handwheel or a micrometer knob that can be locked with a key.
