Description
Maximum Operating Pressure: Up to 800 kPa (8 bar)
Flow Rate: Up to 750 l/min
MPF Series: Return filters designed to protect the tank from system contamination.
They can be mounted directly on the tank in immersed or semi-immersed positions.
The filter outlet must always remain submerged to avoid air intake or foaming inside the tank.
Available Features:
- Internal threaded connections up to 2" and flanged connections up to 2", supporting flow rates up to 750 l/min
- Multiple connection options for return lines or drain ports
- Fine filtration grade to ensure high fluid cleanliness in the tank
- Bypass valve integrated into the filter element to reduce flow resistance
- 2, 3, or 4 mounting holes to fit various tank surfaces
- O-ring or flat gasket options for different tank surface types
- Dipstick for checking fluid level in the tank (available separately)
- Extension pipe for deep tanks (available separately)
- Diffuser to reduce air entrainment, foaming, and noise (available separately)
- Filler cap for clean fluid filling without additional connections
- Visual, electrical, and electronic clogging indicators
Common Applications:
- Light-duty industrial equipment
- Mobile applications
Filter Housing Materials:
- Head: Aluminum
- Cover:
- Nylon: MPF 020-030-100-104-110
- Aluminum: MPF 181-182-184-191-192-194-400-410-450-451-750
- Tank: Nylon
Bypass Valve:
- Opening pressure: 175 kPa (1.75 bar) ±10%
- Opening pressure: 300 kPa (3 bar) ±10%
Δp Element Type:
- Microfiber filter elements – H series: 10 bar
- Fluid flow through the filter element: Outside to inside
Seals:
- Standard: NBR (A series)
- Optional: FPM (V series)
Temperature Range: -25 °C to +110 °C
Note:
MPF filters are designed for vertical installation.
