Description
This electronic manometer allows you to measure, visualize, and store pressures in one device. It is characterized by easy handling and an extremely robust design in a metal housing.
Often, multiple mechanical pressure gauges are required for accurate measurements over a wide range of pressures. Due to its high accuracy, resolution and long-term stability with a 4 1/2-digit display, this manometer does it with a single device.
Features:
- Units: mbar, bar, PSI, Mpa, kPa, kg/cm²
- Display: MIN/MAX/FS
- Battery level indicator
- Automatic Power Off/On
- Zero (zero point setting)
- Reset (Delete MIN/MAX)
Technical details:
| property | value |
|---|---|
| protection | IP 67 |
| Material housing | Zinc cast with rubber protective case (TPE) |
| accuracy | ± 0.5% FS |
| Sample rate | 10 ms |
| Weight in kg | 0.56 |
| Connection description | Stainless Steel 1/4" BSPP (ISO 228-1), Adapter M16x2 SCA-1/4-EMA-3 |
| Load switching | ≥ 100 Mio. |
| Power supply | 2 x 1.5V batteries (AA) |
| Battery life max. | 1,500 h |
| display | 4.5 Digit LC Text Display with Backlight |
| Pressure measurement range | -1 - 16 bar |
| Material Seal | NBR |
