Description
Applications:
- Conveyor systems
- Metalworking machines
- Agricultural machinery
- Road construction machines
- Mining equipment
- Food industry
- Special vehicles
- Plastic and rubber industry machinery, etc.
Medium: Mineral-based – HLP (DIN 51524) or HM (ISO 6743/4)
Temperature range: -40°C to +140°C
Optimal viscosity: 20 to 75 cSt
Filtration: ISO code 20/16 (Min. recommended fluid filtration: 25 microns)
| TECHNICAL DATA | MT 160 | MT 200 | MT 250 | MT 315 | MT 400 | MT 500 | MT 630 | MT 725 |
|---|---|---|---|---|---|---|---|---|
| Max. displacement (cc/rev) |
161.1 | 201.4 | 251.8 | 326.3 | 410.9 | 523.6 | 631.2 | 724.3 |
| Max. operating speed (rpm) |
622 | 620 | 496 | 382 | 304 | 238 | 197 | 172 |
| Max. torque (daNm) |
47 | 59 | 73 | 95 | 108 | 122 | 130 | 127 |
| Max. power (kW) |
26.5 | 33.5 | 33.5 | 33.5 | 30 | 26.5 | 24.3 | 20.2 |
| Max. operating pressure (bar) |
200 | 200 | 200 | 200 | 180 | 160 | 140 | 120 |
| Max. oil flow (liters/min) |
100 | 125 | 125 | 125 | 125 | 125 | 125 | 125 |
