Description
| Part number | description | current | Protection Level | Air transport | noise level | mass |
|---|---|---|---|---|---|---|
| HEALL0212 | LL 02 12V DC | 5.4 A | IP 68 | 0.16 kg/s | 68 dB(A) | 2.7 kg |
| HEALL0224 | LL 02 24V DC | 2.7 A | IP 68 | 0.16 kg/s | 68 dB(A) | 2.7 kg |
| material | Operating temperature range | Air Inlet Shape | Operating pressure |
|---|---|---|---|
| aluminium | –20°C to +100°C (oil temperature) | wavy | 26 bar (static) |
